Flexible Membrane Switch Keypad with Tactile Feedback for Seamless Operation

Flexible Membrane Switch Keypad with Tactile Feedback for Seamless Operation
Flexible Membrane Switch Keypad with Tactile Feedback for Seamless Operation
Flexible Membrane Switch Keypad with Tactile Feedback for Seamless Operation
Flexible Membrane Switch Keypad with Tactile Feedback for Seamless Operation
Flexible Membrane Switch Keypad with Tactile Feedback for Seamless Operation
Flexible Membrane Switch Keypad with Tactile Feedback for Seamless Operation
Flexible Membrane Switch Keypad with Tactile Feedback for Seamless Operation

Flexible Membrane Switch Keypad with Tactile Feedback for Seamless Operation


Electronic

● Circuit Rating: 35V(DC),100mA,1W

● Resistance: 10Ω-500Ω

● Insulation Resistance: 100MΩ100V

● Dielectric Strength: 250VRms (50-60Hz 1min)

● Contact Bounce:  ≤5ms

● Life Expectancy:  Flat: ≥5 Million Times       Tactile: ≥1 Million Times

Mechanical

● Operation Pressure: Flat 57-284g (2-10oz), Tactile 170-397g (6-14oz)

● Switch Stroke: Flat 0.1-0.5mm, Tactile 0.6-1.5mm

Environment

● Operation Temperature:-40℃-+80℃

● Storage Temperature:-40℃-+80℃

Product description

Product parameters

Electronic


● Circuit Rating: 35V(DC),100mA,1W


● Resistance: 10Ω-500Ω


● Insulation Resistance: 100MΩ100V


● Dielectric Strength: 250VRms (50-60Hz 1min)


● Contact Bounce:  ≤5ms


● Life Expectancy:  Flat: ≥5 Million Times       Tactile: ≥1 Million Times


Mechanical


● Operation Pressure: Flat 57-284g (2-10oz), Tactile 170-397g (6-14oz)


● Switch Stroke: Flat 0.1-0.5mm, Tactile 0.6-1.5mm


Environment


● Operation Temperature:-40℃-+80℃


● Storage Temperature:-40℃-+80℃


This flexible membrane switch keypad offers exceptional versatility and durability for a wide range of applications. The flexible design allows for easy integration into curved or irregular surfaces, making it ideal for custom control panels and handheld devices. It provides tactile feedback with each press, ensuring users enjoy a responsive, smooth, and seamless experience. The high-quality materials ensure long-lasting performance, even in demanding environments. With customizable layouts and options for backlighting, this keypad excels in both functionality and user experience, making it perfect for consumer electronics, medical devices, and industrial equipment.
