Electronic

● Circuit Rating: 35V(DC),100mA,1W

● Resistance: 10Ω-500Ω

● Insulation Resistance: 100MΩ100V

● Dielectric Strength: 250VRms (50-60Hz 1min)

● Contact Bounce:  ≤5ms

● Life Expectancy:  Flat: ≥5 Million Times,Tactile: ≥1 Million Times

Mechanical

● Operation Pressure: Flat 57-284g (2-10oz), Tactile 170-397g (6-14oz)

● Switch Stroke: Flat 0.1-0.5mm, Tactile 0.6-1.5mm

Environment

● Operation Temperature:-40℃-+80℃

● Storage Temperature:-40℃-+80℃



Product description

Product parameters

Thin film switch is an electrical switch made of thin film materials, which has various advantages and wide applications. Here are some of the main advantages and application areas of membrane switches:


advantage

Simple structure: The design of membrane switches is simple, usually composed of multiple layers of thin materials, making it easy to produce and install.

Small space occupation: Compared to mechanical switches, membrane switches have a smaller volume and can be used in limited spaces.

Lightweight: Due to material and design reasons, membrane switches are lightweight and suitable for portability.

Dustproof and Waterproof: Membrane switches generally have good dustproof and waterproof effects, suitable for use in harsh environments.

Multiple functions: Multiple functions can be integrated on a switch panel, such as LED indicators, audio functions, etc., to meet diverse needs.

Smooth operation: Good tactile sensation, no mechanical wear on the buttons, more durable.

Beautiful appearance: The membrane switch can print various patterns and text. The appearance design can be customized according to needs to enhance the beauty of the product.


application

Home appliances such as microwave ovens, rice cookers, air conditioners, etc., membrane switches can be used for control panels.

Industrial equipment: used in various industrial control systems, such as machinery and equipment, instruments and meters, etc.

Consumer electronics products: widely used in portable electronic devices such as telephones, calculators, speakers, etc.

Medical equipment, such as medical instruments, monitors, automatic drug dispensers, etc., membrane switches are suitable due to their hygienic and easy to clean characteristics.

Automotive electronics: Used in cars to control various functions such as navigation systems, air conditioning systems, and panels.

Security equipment: such as access control systems, alarms, etc., membrane switches can also be used as control interfaces.


Thin film switches have become an indispensable and important component of modern electronic products due to their excellent performance and diverse application scenarios.
