  • Touch Media:Finger, Touch Pen

  • Surface Hardness:3H or more

  • Circuiting Rating:5V DC,35mA

  • Hitting Life Expectancy:Over 1 million

  • Light Transmission:Film+Film>77%,Film+Glass>83%

  • Scoring Life Expectancy:Over 100,000

  • Contact Bounce:<10ms

  • Operating Temperature:-20℃~+70℃

  • Resolution:4096*4096

  • Storage Temperature:-30℃~+80℃

  • Linearity:1.5%(<1.0% By Request)

  • Choices of Glass Thickness:0.55mm,0.7mm,1.1mm,2.0mm,3.0mm

  • Operating Force:10g-100g

  • Choices of Glass:Normal Glass,Chemically strengthene



Product description

Product parameters

Customizable resistive screens, as a touch screen technology with a long history and mature technology, still have irreplaceable advantages in specific application fields. Its main advantages are reflected in cost-effectiveness, environmental adaptability, and precise operability.


Firstly, compared to new technologies such as capacitive screens, the production cost of resistive screens is lower, especially in scenarios that require large-scale application and low display performance requirements. Customized resistive screens can effectively reduce overall costs.

Secondly, resistive screens have strong adaptability to the environment. It is not affected by factors such as temperature, humidity, static electricity, and can be operated through objects such as gloves and pens, which makes it widely applicable in harsh environments such as industrial control and medical equipment. For example, in factory workshops with high levels of dust, operators wearing gloves can also operate equipment accurately.


Finally, resistive screens have advantages in precise operation. Due to its reliance on physical pressure for touch control rather than capacitive sensing, it can achieve more precise positioning, especially in applications that require high accuracy such as handwritten signatures and chart drawing.


Based on the above advantages, customizable resistive screens are widely used in industrial control panels, medical equipment, POS machines, ATM machines, and other fields. Although its display effect is relatively limited, its low cost, high reliability, and environmental adaptability make it have lasting vitality in specific fields, and through customized design, it can better meet the needs of different industries and continue to exert its unique value.
