Electronic

● Circuit Rating: 35V(DC),100mA,1W

● Resistance: 10Ω-500Ω

● Insulation Resistance: 100MΩ100V

● Dielectric Strength: 250VRms (50-60Hz 1min)

● Contact Bounce:  ≤5ms

● Life Expectancy:  Flat: ≥5 Million Times,Tactile: ≥1 Million Times

Mechanical

● Operation Pressure: Flat 57-284g (2-10oz), Tactile 170-397g (6-14oz)

● Switch Stroke: Flat 0.1-0.5mm, Tactile 0.6-1.5mm

Environment

● Operation Temperature:-40℃-+80℃

● Storage Temperature:-40℃-+80℃



Product description

Product parameters

As a human-computer interaction interface, membrane switches have been widely used in various industries due to their unique advantages. Its advantages are mainly reflected in the following aspects:

Firstly, the cost-effectiveness is significant. The membrane switch has a simple structure and relatively mature manufacturing process, making large-scale production possible and reducing production costs. This is undoubtedly an important advantage for products that require a large number of human-computer interaction interfaces.

Secondly, the design has high flexibility. Membrane switches can be customized according to different application requirements, including button shape, color, functional layout, etc. This flexibility enables it to meet various complex and specific application scenarios.

Once again, it combines durability and reliability. High quality membrane switches have good waterproof and dustproof performance, and can withstand a certain degree of mechanical pressure and chemical corrosion. It has a long service life, high reliability, reduces maintenance and replacement frequency, and lowers overall usage costs.

Finally, the interface is aesthetically pleasing and concise. The membrane switch can be designed with various patterns and text to make its interface more beautiful and concise, enhancing the overall grade of the product.

Based on the above advantages, the application fields of membrane switches are very extensive. In the field of medical equipment, such as ventilators, monitors, etc., high reliability and cleanliness are required, and membrane switches can meet these requirements. In the field of industrial control, such as CNC machine tools, PLCs, etc., stable operation is required in harsh environments, and the durability of membrane switches makes them an ideal choice. In the field of household appliances, such as microwave ovens, washing machines, etc., a beautiful and simple interface is required, and the design flexibility of membrane switches enables them to be well integrated into product design. In the field of instrumentation, membrane switches are also widely used in various testing and measuring equipment, providing a stable and reliable operating interface.
